Product Highlights
1、Complied with test profiles of State Grid
2、Automation test with multi-point control, test results can be sent back automatically
3、Multi-channels simultaneous testing available
4、Multiple test items can be grouped and tested together
5、Simple test environment setup, high test efficiency and stability
? Meet the test profiles of Q/GDW 11202.5—2018 of State Grid
? Automatically test the functions and performance of master-slave clocks, as well as the timing synchronous management function of time serviced equipment
? Support test ports:1PPS, Power IRIG-B（DC/AC）, Serial Time Message, NTP, PTP
? Automatically test the whole group of timing synchronous system with double master clocks networking or master-slave clocks networking
? Test items can be grouped and tested flexibly, and it generates the test sequence to test automatically
? Load the test items and templates automatically in accordance with selected profiles
|
Items |
Descriptions |
|
|
Timing synchronization system tester |
GNSS Receiver |
GPS，BDS，GLONASS，Galileo |
|
Clock Source |
Built-in Rubidium Oscillator or External Reference |
|
|
Time Measurement Interface |
1PPS, xPPS, 1PPS+TOD, IRIG-B（AC）, IRIG-B（DC）, Serial Time Message, NTP/SNTP, PTP |
|
|
Time Output Interface |
1PPS, xPPS, 1PPS+TOD, IRIG-B（AC）, IRIG-B（DC）, Serial Time Message, NTP/SNTP, PTP |
|
|
Standards Supported |
ITU-T G.811, G812, G.813, G.823, G.8261, G.8262, G.8265, G.8266、G.8265.1, G.8271, G.8271.1, G.8272, G.8272.1, G.8273、G.8273.2, G.8275.1, G.8275.2, C37.238, IEEE1588V2, O.171, O.172, GJB2991A, DL/T 1100.1 |
|
|
Communication Ports |
4×USB, 10/100BASE-T Ethernet |
|
|
Platform & System |
x86 CPU，CPU：2.7/3.7GHz；128GB inner memory |
|
|
Power Supply |
AC 90~264V |
|
|
LCD |
13.3”TFT，Capacitance touchscreen |
|
|
Main Frame |
CPU E-2200 Series/ 3.5GHz； 8G internal memory； 1TB（SATA） Hard Disk；23.8’Display |
|
|
Network Switch |
24 Ports；Rate 1000Mbps（Electrical） |
|
|
Satellite Simulator |
Frequency Spots |
GPS：L1 C/A、L1C、L1P；L2C、L2P；L5I、L5Q |
|
BDS：B1I、B1C；B2I、B2a、B2b；B3I |
||
|
Satellite Signal Divider |
One to eight GNSS Satellite Signal Divider（1 channel input, 8 channels output） |
|
|
MMS Protocol Converter |
From DL61850 to 104；Main and standby Ethernet Ports |
|
|
Intelligent Power Supply |
Input Voltage：176~254VAC /12A / 50~60 Hz Current Output: 2 Channels/ Phoenix Ends/220VDC/ 3A One Way 10/100M Ethernet Port, to manage and control the power supply remotely |
|
